Working process:
Put the containers on the labeling machine conveyor, the containers will be sent into bottle
distributing area, the bottles move continuous, after version optical inspect the bottles, it
transport the electrooptical signal to PLC. After PLC processed, the output signal will be
transported to stepper motor. The stepper motor distribute the labels. Through rolling
structure put the labels on the bottle.
Model | TB-100 |
Production speed | 30-100B/Min(according to container and label size) |
Container height | 20mm-300mm(can be customized) |
Label precision | +1mm(according to container feature, hardness and shape) |
Voltage | AC220V, 50/60HZ |
Power | 250W |
Label specification | H: 20mm-200mm L:20-200m(can be customized) |
Paper roll inner diameter | Φ76mm paper roll outer diameter：Φ350（max.） |
Weight | 200Kg |
Overall dimension | 1800X700X1100mm |
